Why you should choose a SmartPS-100A-S0
from Huawei now.
The Huawei SmartPS-100A-S0 is a single-phase current sensor for connection to the inverter. It is easy to operate and read out data via the integrated LCD screen. In addition, the component supports RS485 communication so that the measured values can be evaluated elsewhere. Commissioning of the current sensor for PV systems is easy and safe - the digital wizard guides through integration. Once installed by one-click, the component meets the highest demands. The SmartPS-100A-S0 is designed for use at industrial level and is particularly reliable.
The sensor's technical data is also convincing. For example, its own power consumption is less than one watt - so the device works without consuming much power itself. The possible operating temperature is specified as -25 °C to +60 °C, and the relative humidity can be 5% to 95%. The dimensions of 100 x 36 x 65.5 mm show that this is a compact component. It is mounted on the DIN35 top-hat rail. The input voltage is 176 VAC~288 VAC (phase / N). In operation, the SmartPS-100A-S0 achieves a measurement accuracy of +/-1% (current, power and energy) and +/-0.01 Hz (frequency). The current sensor thus belongs to accuracy class >1. The scope of delivery includes necessary accessories, which are a folding current transformer with 5 m cable length and an RS485 cable with 10 m length.
- 1-phase Smart Power Sensor
- 176-288 Volt Voltage
- Accuracy class > 1
- Easy operation via LCD display
- Power consumption ≤1 W
- Communication via RS485

Secure
Commissioning Wizard

Smart
One-Click Commissioning

Reliable
Industrial level application and high reliability
Huawei SmartPS-100A-S0 - Technical Specifications
All the latest facts and figures
summarized compactly for you.
Huawei SmartPS-100A-S0 - General Specifications
Operating temperature range: -25°C ~ +60 °C
Relative humidity: 5 % RH~ 95 % RH
Dimension (W x D x H): 100 x 36 x 65.5 mm
Mounting type: DIN35 rail
Weight (including cable): 1.2 kg
Power supply type: 1P2W (1-phase)
Input voltage: 176 VAC~288 VAC (phase / N).
Power consumption: ≤ 0.8 W
Communication: RS485
Huawei SmartPS-100A-S0 - Communication
Interface: RS485
Baud rate: 115,200bps (default 9,600bps)
Communication protocol: Modbus-RTU
Huawei SmartPS-100A-S0 - Measuring range
Phase voltage: 176 Vac ~ 288 Vac
Current: 0 ~ 100 A
Huawei SmartPS-100A-S0 - Measurement Accuracy
Voltage: ±0.5 %
Current/ Power/ Energy: ±1 %
Frequency: ±0.01 Hz
Huawei SmartPS-100A-S0 - Environmental Conditions
Operating temperature: -25 ℃ ~ +60 ℃
Storage temperature: -40 ℃ ~ +70 ℃
Operating humidity: 5%RH ~ 95%RH (non-condensing)
Huawei SmartPS-100A-S0 - included in the scope of delivery
1x folding current transformer (5 m cable length)
RS485 (10 m cable length)
