HUWAEI SUN2000-330KTL-H1 Smart String Inverter buy at HYTECH
Why you should choose a HUWAEI SUN2000-330KTL-H1 Smart String Inverter from Huawei now.
HUWAEI SUN2000-330KTL-H1 Smart String Inverter is an uncompromisingly powerful module for large-scale solar power systems. It converts the generated electricity from sunlight into grid-standard alternating current. This is available on site or for feeding into the grid. The dimensions of 1,048 x 732 x 395 mm are compact for an inverter in this power class, and the weight is 112 kg. Installation is therefore best done in pairs or threes. The DC connection to the PV system is made via plug-in connections, so commissioning is completed quickly. The Huawei FusionSolar app helps with the setup. The HUWAEI SUN2000-330KTL-H1 smart string inverter also connects effortlessly with smart components. It supports RS485 communication, for example, with the smart logger. The data can be viewed via the FusionSolar management system.
In summary, the HUWAEI SUN2000-330KTL-H1 Smart String Inverter offers numerous advantages, among other things, the module already has overvoltage protection (type 2 for DC and AC). In addition, 6 MPP trackers are installed at the factory. Pleasant is also the low noise thanks to a modern Smart Air Cooling. The power of 300,000 watts meets the needs of a large system, the MPPT voltage range is between 500 and 1500 volts. The maximum efficiency reaches an amazing 99.0%, the European efficiency 98.8%. All this ensures a high yield in operation.
HUWAEI SUN2000-330KTL-H1 Smart String Inverter Advantages
- 3-phase WR with VA power
- 6 independent MPP trackers
- 4/5/5/4/5/5 DC connections
- Efficiency up to 99.0%
- Communication via RS485, MBUS, WLAN + APP
- Transformerless
- RS485 and MBUS communication for SmartLogger
- Integrated AC and DC overvoltage protection TYPE II
- Smart IV-Curve Diagnosis
- String Smart DC Switch
- Smart Air Cooling
- Protection class IP66
Higher yield
Max. Efficiency 99.0%
Smart DC Connector
With temperature monitoring
Accurate monitoring of the currents
for all strings
Protection class
IP 66
Smart
Maintenance free fan
Smart
String level shutdown
Support
Supports IV curve diagnosis
Surge arrester
for
DC & AC
HUWAEI SUN2000-330KTL-H1 Smart String Inverter
All facts and figures are summarised for you in a compact and up-to-date form at.
SUN2000-330KTL-H1
Smart String Inverter - General Data
Betriebstemperaturbereich: -25 ~ +60 °C
Relative Betriebsfeuchtigkeit: 0 % RH~100 % RH
Betriebshöhe: max. 4.000 m
Kühlung: Smart Air Cooling
Anzeige: Status LED´s
Kommunikation: 4G / 3G / 2G via Smart Dongle – 4G (Optional), MBUS
Gewicht (mit Montageplatte): 112 Kg
Abmessungen: 1.048 x 732 x 395 mm
Schutzart: IP66
Topologie: Transformatorlos
Energieverbrauch nachts: < 3.5 W
SUN2000-330KTL-H1
Smart String Inverter - Input DC
Max. Input voltage1: 1.500 V
MPPT operating voltage range2: 500 V ~ 1,500 V
Starting voltage: 550 V
Rated input voltage : 1.080 V
Max. Input current per MPPT: 65 A
Max. Short circuit current: 115 A
Number of MPP trackers: 6
Number of inputs: 28
SUN2000-330KTL-H1
Smart String Inverter - Output AC
Netzanschluss: Dreiphasig
Nennleistung: 300.000 W
Maximale Scheinleistung: 330.000 VA
Nennausgangsspannung: 800 V, 3W + PE
Maximaler Ausgangsstrom: 238.2 A
Einstellbarer Leistungsfaktor: 0.8 kap. … 0.8 ind.
Klirrfaktor (THD): < 1%
HUWAEI SUN2000-330KTL-H1 Smart String Inverter Efficiency
Max. Efficiency: ≥ 99.0%
European efficiency: ≥ 98.8%
HUWAEI SUN2000-330KTL-H1 Smart String Inverter - Protection Devices
DC load break switch: Yes
Islanding detection: Yes
AC overcurrent protection: Yes
DC reverse polarity protection: Yes
String monitoring: Yes
DC surge arrester: Type II
AC surge arrester: Type II
Insulation monitoring: Yes
Fault current monitoring: Yes
HUWAEI SUN2000-330KTL-H1 Smart String Inverter - Standards and Safety
EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 61727, IEC 60068, IEC 61683
HUWAEI SUN2000-330KTL-H1 Smart String Inverter - Mains Connection Conditions
VDE-AR-N4105, VDE 4110, EN 50549-1, EN 50549-2, RD 661, RD 1699, C10/11
Further information on standard conformity available on request.
HUWAEI SUN2000-330KTL-H1 Smart String Inverter - included in delivery
PV connector
Bluetooth dongle (for commissioning via FusionSolar app)
Bracket
HUWAEI SUN2000-330KTL-H1 Smart String Inverter - Notes and Explanations
1 The maximum input voltage is the upper limit of the DC voltage. Any higher input DC voltage would likely damage the inverter.
2 Any DC input voltage above the operating voltage range can lead to faulty operation-.
* via 4G dongle (optional)
** works with Smartlogger300A03 (transformer required)
